Metcal STTC-144 Bent Long Reach Conical Solder Tip

Metcal STTC-144 is a 30° bent long reach conical sharp tip soldering cartridge, that is used with the MX-500, MX-5000 systems, with MX-RM3E and MX-H1-AV hand pieces. It offers a variety of tasks for through hole and SMD rework. Metcal recommends the 700-series for the majority of applications.

Features & Benefits:

• 0.5mm x 14.5mm
• 30° bent long reach conical sharp tip
• The 700-series have a temperature range up to 390°C
• Can be used with leaded and lead-free solder
• Metcal "SmartHeat Technology" automatically adjusts power levels during each soldering operation

SmartHeat Process Control:

The technology built into every Metcal SmartHeat® system means that soldering and rework are always performed at safe, controlled temperatures. Metcal users know that moderate fixed temperatures, where power is varied, provide the best assurance for a well-controlled soldering and rework process.
